GMC-BM28 Series

Gaming Mini PC Intel Xeon D-1581, 16 Cores, GeForce GTX 1650 4G

For product pricing, customization, or other inquiries:

Share to:




Small body, big energy. It is the stronger and smoother performance gaming mini pc. Master the power of the core, multi-threaded processing and multi-tasking, easy to deal with office design, audio and video, online shopping, games, etc. 4K audio and video, cinema quality. With GeForce GTX 1650 4G graphics. Unlock high-effect picture quality and be on the scene. Picture quality and special effects field of view are indispensable. DDR5 video memory ensures that 1080P picture quality is not turned on. Multi-capture anti-aliasing is still smooth. Feel the immersive and stunning picture quality. Every game is a blockbuster movie.

Key Features

GMC-BM28 Series Intel® Xeon® D-1581 BGA Processor and Intel® SOC Chipset

GMC-BM28 Series Rich I/O: DVI, DP, HDMI, DC, LAN, 2 x USB 3.0, 4 x USB 2.0, Spk, Mic

GMC-BM28 Series Dual SODIMMs for up to 128GB DDR4 Memory

GMC-BM28 Series Rich Storage: 1 x M.2 2280 SATA/NVME SSD, 1 x M.2 2280 NVME SSD, 1 x 2.5 Inch SSD/HDD

GMC-BM28 Series Embedded Expansion: M.2 PCIe for WiFi


Key Functions

GMC-BM28 Series Support diskless boot

GMC-BM28 Series Support Restore AC Power Loss

GMC-BM28 Series Support 3-channel display out(DP, HDM and DVI) for simultaneous display or synchronous different display

GMC-BM28 Series Support up to 8K output, 4K DP1.4, HDMI2.0 and DVI-D





Material Aluminum alloy
Colour Silver
Size 280 x 200 x 52mm
Weight 2.5Kgs
Insallation Method Desktop type/vesa mounting
With holding vertical stand, vesa mount as the optional


CPU Intel® Xeon® Processor D-1581 24M Cache, 1.80 GHz (16 cores 32 threads)
Chipset SOC
Network Card 1 x Intel RTL 8168/8111/8112 gigabit lan
WiFi and Bluetooth With dual antennas, 802.11ac 2.4+5Ghz, bt 4.0/4.2
Memory 2 x SODIMM DDR4, up to 64GB RAM
Storage 1 x 2.5 inch hard disk bay/1 x M.2 2280 (SATA/NVME)/1 x M.2 2280 (NVME)
Expand 1 x M.2 PCIE WiFi slot, ( (SIM slot optional for customization)

I/O Interfaces

Front Panel 1 x Power button
2 x USB2.0
Rear Panel 1 x Audio
2 x USB2.0
1 x Lan
2 x USB3.0
1 x DC_in
1 x DP
1 x HDMI
1 x DVI
2 x WiFi antennas

Software Support

Bios AMI bios
System Support Windows 10, linux ubuntu etc


Cooling Mode Smart silent fan (place it vertically to reduce the fan speed & sound effectively)
Power Supply DC100-240V AC/50-60Hz, DC 19V/9.5A
Packing List BM28 mini pc, power supply, power cord, vertical stand, wifi antennas, warranty card


Operating Temperature 0°C~70°C Centigrade (32°F~140°F)
Storage Temperature -20°C~80°C Centigrade (-68°F~176°F)
Relative Humidity 10%~90% (non-condensing)
Certification GMC-BM28 Series


* Ordering Information *























BM28-D-1581 Xeon D-1581 GeForce GTX 1650 4G 1.8~2.4 GHz 65 W DP/HDMI/DVI 2 x SO-DIMM DDR4, up to 64GB 1 x 2.5 inch/1 x M.2 2280 (SATA/NVME)1 x M.2 2280 (NVME) 1 6 19V/9.5A


* Supplemental Information *


Installation Method:  Support multiple fixing methods such as desktop type, vesa mounting type etc

Optional Accessories:

Memory: 4G/8G/16G/32G/64G DDR4 RAM type

Storage: 64G/128G/256G/512G SSD/1TB solid state drive etc

1TB/2TB/3TB/5TB 2.5 inch hard drive etc

Optional 19V 9.5A adapter, optional power cords such as national standard, American standard, British standard, European standard, Australian standard
